SFF - Core i7 10700 / up to 4.8 GHz - vPro - RAM 16 GB - SSD 512 GB - NVMe, TLC - DVD-Writer - UHD Graphics 630 - Gigabit Ethernet - Win 10 Pro 64-bit - monitor: none - keyboard: US - Smart Buy
| Main Specifications | |
|---|---|
| Product Description | HP EliteDesk 800 G6 - SFF Core i7 10700 2.9 GHz - vPro - 16 GB - SSD 512 GB - US |
| Type | Personal computer - SFF |
| Platform Technology | Intel vPro Platform |
| Localization | Language: English / region: United States |
| Processor | Intel Core i7 (10th Gen) 10700 / 2.9 GHz (, up to 4.8 GHz, (8-core) |
| Processor Main Features | Intel Turbo Boost Technology 2, Intel Smart Cache |
| Cache Memory | 16 MB |
| Cache Per Processor | 16 MB |
| RAM | 16 GB (installed) / 128 GB (max) - DDR4 SDRAM - non-ECC |
| Storage Controller | SATA (SATA 6Gb/s) |
| Hard Drive | SSD 512 GB - PCI Express 3.0 - M.2 2280 - NVM Express (NVMe), triple-level cell (TLC) |
| Optical Storage | DVD-Writer |
| Graphics Controller | Intel UHD Graphics 630 Dynamic Video Memory Technology |
| Audio Output | Stereo |
| Networking | 1GbE |
| Keyboard | US |
| Power | AC 120/230 V (50/60 Hz) |
| OS Provided | Windows 10 Pro 64-bit Edition |
| Dimensions (WxDxH) | 13.3 in x 12.1 in x 3.9 in |
| Weight | 13.51 lbs |
| Manufacturer Selling Program | HP Smart Buy |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | Limited warranty - parts and labor - 3 years - on-site |
| General | |
| Platform Technology | Intel vPro Platform |
| Type | Personal computer |
| Product Form Factor | SFF |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Language: English / region: United States |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 2.5" ¦ 2 (total) / 2 (free) x internal 3.5" ¦ 1 (total) / 0 (free) x external 5.25" Slim Line |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2230 ¦ 2 (total) / 1 (free) x M.2 Card - 2230/2280 (x4 mode) ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (75W max power) |
| Interfaces | 2 x USB 2.0 ¦ 4 x USB 3.2 Gen 1 (2 front, 2 rear) (one of them is fast-charging) ¦ 4 x USB 3.2 Gen 2 (2 front, 2 rear) ¦ 1 x USB-C 3.2 Gen 2 (1 in front) ¦ 3 x DisplayPort ¦ 1 x headphones/microphone (1 in front) (CTIA headset support) ¦ 1 x audio line-out ¦ 1 x LAN |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type | Kensington security slot |
| Compliant Standards | ACPI, CCC, RoHS, WEEE, Common Criteria EAL4+, CECP, SEPA, low halogen |
| Manufacturer Selling Program | HP Smart Buy |
| RAM | |
| Installed Size | 16 GB (installed) / 128 GB (max) |
| Technology | DDR4 SDRAM - non-ECC |
| Effective Memory Speed | 2933 MHz |
| Rated Memory Speed | 2933 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 3 (empty) |
| Features | Unbuffered |
| Configuration Features | 1 x 16 GB |
| Networking | |
| Ethernet Controller | Intel I219-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | SNMP 2 |
| Features | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az |
| Power | |
| Device Type | Power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 260 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Power Factor Correction | Yes (active) |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Storage Controller | |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 3 |
| Cache Memory | |
| Installed Size | 16 MB |
| Cache Per Processor | 16 MB |
| Optical Storage | |
| Type | DVD±RW DVD-Writer - SATA |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 630 Dynamic Video Memory Technology |
| Video Interfaces | DisplayPort |
| HDCP Compatible | Yes |
| Audio Output | |
| Sound Output Mode | Stereo |
| Max Sampling Rate | 192 kHz |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | Windows 10 Pro 64-bit Edition English |
| Hard Drive | |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 512 GB |
| Interface Type | PCI Express 3.0 |
| Features | NVM Express (NVMe), triple-level cell (TLC) |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Width | 13.3 in |
| Depth | 12.1 in |
| Height | 3.9 in |
| Weight | 13.51 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 15.7 in |
| Shipping Depth | 19.6 in |
| Shipping Height | 9.1 in |
| Shipping Weight | 19.84 lbs |
| Keyboard | |
| Keyboard Name | HP 320K |
| Interface | USB |
| Localization & Layout | US |
| Mouse | |
| Mouse Name | HP 320M |
| Technology | Optical |
| Interface | USB |
| Processor / Chipset | |
| CPU | Intel Core i7 (10th Gen) 10700 |
| Clock Speed | 2.9 GHz |
| Max Turbo Speed | 4.8 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Processor Main Features | Intel Turbo Boost Technology 2, Intel Smart Cache |
| Chipset Type | Intel Q470 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
