SFF Ryzen 5 8500G / up to 5 GHz - RAM 16 GB - SSD 256 GB - NVMe - Radeon 740M - Gigabit Ethernet - Win 11 Pro - monitor: none - keyboard: US - Smart Buy - with HP Wolf Pro Security Edition (1 year)
| Main Specifications | |
|---|---|
| Product Description | HP Elite 805 G9 - SFF Ryzen 5 8500G 3.5 GHz - 16 GB - SSD 256 GB - US - with HP Wolf Pro Security Edition (1 year) |
| Type | Personal computer - SFF |
| Localization | Language: English / region: United States |
| Processor | AMD Ryzen 5 8500G / 3.5 GHz (up to 5 GHz, (6-core) |
| Cache Memory | 16 MB L3 cache |
| Cache Per Processor | 16 MB |
| RAM | 16 GB (installed) / 128 GB (max) - DDR5 SDRAM |
| Storage Controller | SATA (SATA 6Gb/s) |
| Hard Drive | SSD 256 GB - PCI Express - M.2 - NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Graphics Controller | AMD Radeon 740M |
| Audio Output | Stereo |
| Networking | 1GbE |
| Keyboard | US |
| Power | (50/60 Hz) |
| OS Provided | Windows 11 Pro |
| Software Included | HP Support Assistant, HP BIOSphere, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Sure Recover, HP Privacy Settings, HP Sure Sense, HP Sure Admin, HP Wake on WLAN, HP Desktop Support Utility, myHP, Touchpoint Customizer for Commercial, HP Desktop Support Utilities, HP Noise Cancellation Software, HP Easy Clean |
| Dimensions (WxDxH) | 13.3 in x 12.1 in x 3.9 in |
| Weight | 11.9 lbs |
| Manufacturer Selling Program | HP Smart Buy |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | Limited warranty - parts and labor - 1 year |
| Bundled with | HP Wolf Pro Security Edition (1 year) |
| General | |
| Type | Personal computer |
| Product Form Factor | SFF |
| Sensors | HP Tamper Lock |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Language: English / region: United States |
| Bundled with | HP Wolf Pro Security Edition (1 year) |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 3.5" |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2230 (for wireless module) ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (for internal storage) ¦ 1 (total) / 1 (free) x Flex I/O ¦ 1 (total) / 1 (free) x PCIe 3.0 x1 ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 |
| Interfaces | 1 x USB-C 3.2 Gen 2x2 (1 front) (charging) ¦ 4 x USB 3.2 Gen 2 - Type A (4 front) (one of them is charging) ¦ 1 x headphones/microphone (CTIA headset support) ¦ 1 x DisplayPort 1.4a (1 rear) ¦ 2 x USB 3.2 Gen 1 - Type A (2 rear) ¦ 4 x USB 2.0 - Type A (4 rear) ¦ 1 x HDMI (1 rear) ¦ 1 x LAN (Gigabit Ethernet) (1 rear) ¦ 1 x audio line-out/line-in (1 rear) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 1 year |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor |
| Security Slot Type | Kensington security slot |
| Compliant Standards | FCC Class B certified, VCCI, ICES-003, FIPS 140-2 Level 2, RoHS, UL 60950-1, CCC Class B, KCC, WEEE, KCC Class B, UL 62368-1, CSA C22.2 No. 62368-1-14 |
| Manufacturer Selling Program | HP Smart Buy |
| RAM | |
| Installed Size | 16 GB (installed) / 128 GB (max) |
| Technology | DDR5 SDRAM |
| Effective Memory Speed | 2800 MHz |
| Rated Memory Speed | 2800 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 3 (empty) |
| Features | Unbuffered |
| Configuration Features | 1 x 16 GB |
| Networking | |
| Ethernet Controller | Realtek RTK8111EPP |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | SNMP 2 |
| Features | Wake on LAN (WoL), auto-uplink (auto MDI/MDI-X), PXE 2.1 support |
| Power | |
| Device Type | Power adapter |
| Voltage Required | AC 90-264 V (50/60 Hz) |
| Power Provided | 260 Watt |
| Efficiency | 92% |
| Power Factor Correction | Yes (active) |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% RH (non-condensing) |
| Storage Controller | |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 3 |
| Cache Memory | |
| Installed Size | L3 cache - 16 MB |
| Cache Per Processor | 16 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | AMD Radeon 740M |
| Video Interfaces | HDMI, DisplayPort |
| HDCP Compatible | Yes |
| Audio Output | |
| Sound Output Mode | Stereo |
| Max Sampling Rate | 192 kHz |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | Windows 11 Pro English |
| Software | HP Support Assistant, HP BIOSphere, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Sure Recover, HP Privacy Settings, HP Sure Sense, HP Sure Admin, HP Wake on WLAN, HP Desktop Support Utility, myHP, Touchpoint Customizer for Commercial, HP Desktop Support Utilities, HP Noise Cancellation Software, HP Easy Clean |
| Hard Drive | |
| Type | SSD - M.2 |
| Capacity | 1 x 256 GB |
| Interface Type | PCI Express |
| Features | NVM Express (NVMe) |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Width | 13.3 in |
| Depth | 12.1 in |
| Height | 3.9 in |
| Weight | 11.9 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 15.7 in |
| Shipping Depth | 19.6 in |
| Shipping Height | 9 in |
| Shipping Weight | 17.02 lbs |
| Keyboard | |
| Keyboard Name | HP 320K |
| Interface | USB |
| Localization & Layout | US |
| Mouse | |
| Mouse Name | HP 125 |
| Processor / Chipset | |
| CPU | AMD Ryzen 5 8500G |
| Clock Speed | 3.5 GHz |
| Max Turbo Speed | 5 GHz |
| Number of Cores | 6-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| L2 cache | 6 MB |
| CPU Upgradability | Upgradable |
| Chipset Type | AMD PRO 665 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| Total CF/unit Standard Deviation (kg CO2e) | 270 |
| Manufacturing (kg CO2e) | 137 |
| Logistics (kg CO2e) | 1 |
| Use (kg CO2e) | 131 |
| EOL (kg CO2e) | 2 |
| Total Carbon w/o Use Phase (kg CO2e) | 270 |
