Network surveillance camera - dome - indoor, outdoor - vandal / weatherproof / tamper-proof - color (Day&Night) - 8 MP - 3840 x 2160 - 4K - fixed focal - audio - LAN 10/100 - DC 37 - 57 V / PoE
| Main Specifications | |
|---|---|
| Product Description | Ubiquiti UniFi Protect G6 Dome - network surveillance camera - dome |
| Device Type | Network surveillance camera - fixed - dome - indoor, outdoor - vandal / weatherproof / tamper-proof |
| Audio | Yes: built-in microphone |
| Camera Mount Type | Wall mount, ceiling mount, flush mount |
| Dimensions (WxDxH) | 5.7 in x 5.7 in x 3.8 in |
| Weight | 28.92 oz |
| Color | Black |
| Connectivity Technology | Wired |
| Camera | Color - Day&Night |
| Max Resolution | 3840 x 2160 |
| Frame Rate (max) | 30 frames per second |
| Video Modes | 4K |
| Optical Sensor Type | 1/1.8" - 8 MP |
| Focal Length Control | Fixed focal |
| Interfaces | Ethernet 10Base-T/100Base-TX |
| Voltage | DC 37 - 57 V / PoE |
| Features | 16:9 aspect ratio, IR-cut filter, night vision infrared imaging, Face Recognition, License Plate Recognition, brightness control, sharpness control, contrast control, white balance, exposure control, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), noise reduction by motion, masking, text overlay, High Dynamic Range (HDR), color control, ARM Cortex A-53 processor, reset button, aluminum alloy housing, Smart Detection, People Detection, Vehicle Detection, animal detection, multi TOPS AI engine, light sensor, LED indicator |
| Environmental Parameters (operating) | -4 °F - 122 °F; 0 - 90% (non-condensing) relative humidity |
| General | |
| Device Type | Network surveillance camera |
| Audio Support | Yes: built-in microphone |
| Form Factor | Dome |
| Camera Mount Type | Wall mount, ceiling mount, flush mount |
| Connectivity Technology | Wired |
| Width | 5.7 in |
| Depth | 5.7 in |
| Height | 3.8 in |
| Weight | 28.92 oz |
| Expansion / Connectivity | |
| Ports | LAN/power - RJ-45 |
| Miscellaneous | |
| Compliant Standards | FCC, IC, IP66, IK10, NDAA, UKCA, EAC, WEEE |
| Color | Black |
| Power | |
| Power Requirements | DC 37 - 57 V / PoE |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 122 °F |
| Relative Humidity (operating) | 0 - 90% (non-condensing) |
| Camera | |
| Type | Color - Day&Night - fixed - indoor, outdoor - vandal / weatherproof / tamper-proof |
| Max Digital Video Resolution | 3840 x 2160 |
| Video Modes | 4K |
| Infrared LEDs | Yes |
| Infrared Distance | 98 ft |
| Digital Video Capture Resolution | 3840 x 2160 |
| Frame Rate (max) | 30 frames per second |
| Features | 16:9 aspect ratio, IR-cut filter, night vision infrared imaging, Face Recognition, License Plate Recognition, brightness control, sharpness control, contrast control, white balance, exposure control, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), noise reduction by motion, masking, text overlay, High Dynamic Range (HDR), color control, ARM Cortex A-53 processor, reset button, aluminum alloy housing, Smart Detection, People Detection, Vehicle Detection, animal detection, multi TOPS AI engine, light sensor, LED indicator |
| Lens Construction | |
| Type | Fixed focal |
| Horizontal Field of View (degree) | 109.9 |
| Vertical Field of View (degree) | 56.7 |
| Diagonal Field of View (degree) | 134.1 |
| Image Sensor | |
| Type | 8 MP 1/1.8" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX |
