Console server - with smart out-of-band management - 8 ports - 1GbE, RS-232 - 4G - 1U - cloud-managed - rack-mountable - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Opengear OM1208 - console server - with smart out-of-band management - cloud-managed - TAA Compliant |
| Device Type | Console server |
| Form Factor | Rack-mountable - 1U |
| Localization | Global |
| Processor | 1 x AMD GX-412TC 1.4 GHz |
| RAM | 4 GB |
| Flash Memory | 16 MB |
| Hard Drive | 16 GB x 1 |
| Ports Qty | 8 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232 |
| Mobile Broadband Access | Yes |
| Generation | 4G |
| Cellular Protocol | LTE Advanced Pro Cat 12 |
| Included Accessories | 4 rubber feet, rack mount kit, 2 x cellular antennas, power adapter, cellular antenna extender |
| Power | AC 110-240 V |
| TAA Compliant | Yes |
| Dimensions (WxDxH) | 8.7 in x 6.7 in x 1.7 in |
| Weight | 2.2 lbs |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Console server |
| Height (Rack Units) | 1U |
| Built-in Devices | 8-port switch |
| Width | 8.7 in |
| Depth | 6.7 in |
| Height | 1.7 in |
| Weight | 2.2 lbs |
| Localization | Global |
| Expansion / Connectivity | |
| Expansion Slots | 2 (total) / 2 (free) x SIM card |
| Interfaces | 8 x RS-232 - RJ-45 ¦ 2 x 1000Base-X - SFP (mini-GBIC) ¦ 2 x USB 3.0 - Type A ¦ 2 x USB 2.0 - Type A ¦ 8 x 1000Base-T - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Included Accessories | 4 rubber feet, rack mount kit, 2 x cellular antennas, power adapter, cellular antenna extender |
| Cables Included | 1 x DB-9 to RJ-45 adapter |
| MTBF | 100,000 hours |
| Compliant Standards | EN 62311:2008, EN 62133:2013, ETSI EN 301 489-1 V2.1.1 (2017-02), ETSI EN 301 489-19 V2.1.1 (2019-04), EN 301 489-52 V1.1.0 (2016-11), FCC Part 15 Subpart B:2015, ICES-003 issue 6, EN 55032:2012, EN 55035:2017, EN 61000-3-2:2014, EN 6100-3-3:2013, EN 301 908-1, EN 301 908-2, EN 301 908-1 V13.1.1, EN 303 413 V1.1.1, IEC 62368-1, CAN/CSA-C22.2, RoHS, NERC-CIP, EN 301 908-13, NAPRD.03 |
| TAA Compliant | Yes |
| Networking | |
| Form Factor | Rack-mountable |
| Ports Qty | 8 |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232 |
| Network / Transport Protocol | IPv4, IPv6, OpenVPN, IPSec |
| Remote Management Protocol | SSH, LDAP |
| Cloud-Managed | Yes |
| Features | Firewall protection, IPv6 support, IPv4 support, Cisco straight pinout, Authentication, Authorization and Accounting (AAA), Python runtime, Zero-touch provisioning (ZTP), Trusted Platform Module 2.0 (TPM 2.0), OpenVPN client, IPSec client, password protection, Smart Out-of-Band, Docker Support, Lighthouse Service Portal (LSP) enabled |
| Authentication Method | RADIUS, TACACS+, Secure Shell (SSH), Active Directory, Kerberos, LDAP |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 110-240 V |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 5 - 90% |
| Communications | |
| Mobile Broadband Access | Yes |
| Generation | 4G |
| Cellular Protocol | LTE Advanced Pro Cat 12 |
| Processor / Memory / Storage | |
| Processors Installed | 1 x AMD GX-412TC 1.4 GHz |
| Max Supported Qty | 1 |
| RAM | 4 GB |
| Flash Memory | 16 MB |
| Hard Drive | SSD 16 GB x 1 - mSATA |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 2 |
